DRB002F Series Stainless Steel Exit Buttons

DRB002F Series Exit Buttons come with either screw terminals (suffix - SWH20) or connection wires. Screw terminal versions are PUSH TO MAKE (COM / NO), cable versions are CHANGE-OVER (COM / NO / NC).

Use DRB-SH aluminium surface shroud (extrusion) if you require surface mounting.

Features:

• Brushed Stainless Steel
• 19mm Stainless Steel button
• Flush mount
• Single Gang
• Dimensions: 85 x 85 (hw mm)

Technical Specifications:

• Max. Rating: 5A/125/250 V AC.
• Contact resistance: 50 milli ohms Max. (Initial).
• Operating travel: 2.7mm.
• Operating life (Mechanical): Over 100,000 times.
• Cables included with change-over versions.
