QT602 Quantec Addressable Call Point, Button Reset c/w Remote Socket

Product Description

  • A programmable addressable call point c/w remote jack socket for use with C-TEC's Quantec Addressable Call System.
  • Includes a Call button, Reset button and red/green confidence light.
  • Can make up to 5 levels of call - Standard, Ensuite, Help Required, Emergency, Presence & Attendance (dependent on configuration and ancillary devices used). Attack and Attendance calls can also be made if connected to compatible slave infrared receiver.
  • Remote socket allows the connection of optional tail call leads, pressure mats, etc.
  • Can be programmed to operate in a multitude of ways using a QT423 configurator.
  • Connections provided for additional slave devices such as ceiling pulls, overdoor lights, slave infrared receivers and more.
  • QT602M magnetic reset version also available.
Power requirements Nominal 24V DC (from Quantec Controller/Network).
Quiescent current Less than 3mA.
Alarm current 14mA.
Indicators Red/green confidence LED.
Controls Call button; Reset button. (QT602M magnetic reset version also available).
Connections Net +: Net -; R; G; L+; SW; IR; SLV.
Expansion connections R; G; L+; SW; IR & SLV terminals allow the connection of optional slave overdoor lights, slave call points, slave ceiling pulls and slave infrared receivers.
Onboard 6.35mm Remote Jack Socket Yes - for the optional connection of tail call leads/pear pushes, pressure mats and movement detectors.
Onboard Sounder No.
Onboard Infrared Receiver No.
Product dimensions (mm) 86 W x 86 H x 30 D mm. Can be mounted on a standard UK 25mm single gang flush or surface back box.
Construction & finish Plastic.
IP Rating IP20.
Weight 72g.
Operating conditions/temperature -5ºC to +40ºC. Max relative humidity: 95%.

Specifications

MPN
QT602
Brand
QUANTEC
Product Code
QT602
